Titan® Overhead Sectional Door
Aluminum / Glass
Our most popular aluminum and glass overhead sectional door.
The Titan® Model from ArmRLite is our most popular aluminum and glass overhead sectional door due to its symmetrical rails and stiles. This model is available with or without windload and can be manufactured up to 24’-2” wide. Since 1958, ArmRLite has been consistently manufacturing the Titan® Model and has never compromised on the quality of our doors. Because of this, ArmRLite is able to produce replacement sections for any of our welded models, regardless of purchase date. In addition, the Titan® Model comes with an unmatched 20-year welded frame warranty except for the top section when trolley operated.
Ideal Applications
Fire stations, truck service facilities, loading docks, manufacturing plants, restaurants, interior partitions, hospitals, and residential homes.
Features
- Maximum Width of 24’ 2”
- Windload Rated
- 20-Year Welded Frame Warranty (Except the top section when trolley operated.)
Specifications
- Material: 6063-T6 Alloy
- Construction Method: Heli-Arc Welding
- Top Rail: 2 ¾”, 4 ½” or 7 ½”
- Bottom Rail: 4 ½” or 7 ½”
- End Stiles: 3 ⅜”, 4 ½” or 7 ½”
- Center Stiles: 3 ⅜”
- Meeting Rails: 3 ⅜” wide per pair
- Frame Thickness: 1 ¾”
Custom Options
Constructed with ArmRLite’s exclusive welding system, our overhead sectional doors offer a wide range of custom options. This customization makes ArmLite the leader in luxurious overhead sectional and garage doors and ensures our customers get the ultimate entrance door solution for their home or business.
Finish Options
ArmRLite offers a wide variety of custom colors and finishes for our aluminum and glass overhead sectional and steel roll up doors. Architects, builders, designers, homeowners, and dealers/installers use these charts to make the ideal selection for their door.
Most Popular
The following are our most popular, cost effective, and best warrantied finishes. They also have the fastest lead times.
Glass Options
Due to our exclusive welded construction, ArmRLite’s aluminum overhead sectional doors are capable of the highest degree of customization. Many of the options listed below are exclusive to ArmRLite due to our superior construction method.
Glass Thickness Options
- 1" insulated
- 1/4" Non-Insulated
- 1/8" Non-Insulated
- 5/8" insulated
- 7/16" insulated
Glass Glazing Options
- Acoustical*
- Acrylic
- Custom
- DSB / Annealed
- Frosted
- Hurricane / Impact
- Insulated
- Laminated
- Polycarbonate
- Tempered / Safety
- Tinted
Interior Panel Options
Due to our exclusive welded construction, ArmRLite aluminum overhead sectional doors are capable of the highest degree of customization. ArmRLite offers a variety of panel options including solid, perforated, stamped, mesh, and louver designs. The panel options provided below are examples of the kinds of customized panel designs you can achieve with ArmRLite, however, more designs are available.
- Custom Panels
- Insulated
- Mesh
- Operable / Inoperable Louvers
- Perforated
- Solid
- Stamped Panel Designs
Titan® Overhead Sectional Door
When Your Entrance Matters!
When you choose ArmRLite for your home’s or commercial building’s entrance solution, you’re making a wise investment that will captivate your customers, impress your neighbors, and protect your family and employees.
Questions?
Call 1-800-554-5816 or email ArmRLite today to discuss how we can make your vision of a luxurious, durable garage door a reality!
